PLC Splitter 1x16 SC/UPC
1*16 PLC Splitter / Optical Fiber Splitter With SC/UPC Connectors With 0.9 / 2.0 / 3.0mm Cable
Description
1*16 PLC Splitter / Optical Fiber Splitter With SC/UPC Connectors With 0.9 / 2.0 / 3.0mm Cable
Quick Details
Brand Name: CY
Model Number: 1*16 PLC
Insertion Loss≤13.8 dB
Return Loss(dB):UPC:50 APC:60
Operating Temperature(°C):-40~85
Connector Type:SC/APC
1.
Specifications
Parameters |
| Units | Remark | |
Channel Number | 1×16 | |||
Operation Wavelength | 1280 ~ 1650 | nm | ||
Insertion Loss | ≤13.7 | dB | ||
Uniformity | ≤1.5 | dB | ||
Polarization Dependent Loss | 0.2 | dB | ||
Return Loss | ≥50 | dB | ||
Directivity | ≥55 | dB | ||
Fiber Type | G657A | |||
Pigtail | Input: 0.9 /2.0/3.0mm Cable | |||
Connector | SC/APC | N/A | <0.3dB |
1.2 Environmental requirements
Parameters |
| Units | Remark | |
Operating Temperature | -40 ~ +85 | °C | ||
Storage Temperature | -60 ~ +85 | °C |
Competitive advantages
Hubei Chenyu Optoelectronics Technology Co., Ltd. strictly implements the ISO9001 quality management system. The company has good facilities and qualified human resources management personnel to ensure stable product quality and excellent performance; and good after-sales services have won the trust of customers , Products are exported to Europe, America and Southeast Asian countries.
| FAQ |
1 . How many staff's we have?
Answer: About 150 well-trained staff and engineers.
2 . When our company be established?
Answer: We started from year 2008.
3 . What's our main products?
Answer: CY dedicates to the developing, production, marketing of the Fiber Optic Cable,
Indoor/Outdoor Patch Cord, Splitter, Adapter, Attenuator, and so on.
4 . What is the area of the factory?
Over 2500 square meters
More than 16 non dust productions lines in total
4 production lines for Fiber Optic Cable
2 high standard MPO/MTP Jumper assembly lines
8 production lines for standard Jumpe
4 PLC Pplitter production lines
5 . What certificate we have?
Answer: ISO 9001: 2008, CPR, UL, RoSH, CE,High and New Tech Enterprise Certficate.
