PLC Splitter 1x32 SC/APC
CY strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, productsexported to Europe and the United States and Southeast Asian countri
Description
Fiber Optic PLC splitter 1x32 SC/APC plastic Box
Quick Details
●Place of Origin: Guangdong, China (Mainland)
●Brand Name: CY/OEM
●Model Number: 1x32 PLC
●Fiber type: 9/125 um SMF-28e or customer appoint
●Connector: FC, SC, LC, ST
●Ferrule Polish: APC,UPC,PC
●Splitting Ratio: 1*2, 1*8, 1*16, 1*32, 2*16, 2*32, 2*64...
●Fiber Diameter: bare fiber, 0.9mm, 2.0mm, 3.0mm
●Operating wavelength(nm): 1260-1650
●Operating temperature: -40℃ - 85℃
●Certifaction: ISO9001, ROHS
Application
1. FTTX networks
2. PON networks
3. CATV links
4. Data Communication
Types:
1. Basic type PLC splitter
2. SFF type PLC splitter
3. 900um Fan-out Type PLC Splitter
4. Cassette type PLC splitter Module
5. Rack type PLC splitter Module
6. Tray assembly PLC splitter Module
7. Flat Quick-Connect Termination Type PLC Splitter Module
|
1. Low Insertion Loss
2. Low Polarization Dependent Loss
3. Wide Operation Wavelength
4. Wide Operation Temperature
5. High Stability and Reliability
6. Telcordia GR-1209 and GR-1221 Compliance
7. YD/T 2000.1-2009 Compliance (TLC Product Certificate Compliance)
Specification
Parameter | Unit | 1×2 | 1×4 | 1×6 | 1×8 | 1×12 | 1×16 | 1×32 | 1×64 | |
Premium Grade | ||||||||||
Insertion Loss at 23°C | Typ. | dB | 3.9 | 6.8 | 9.3 | 10.0 | 12.1 | 13.2 | 16.5 | 20.0 |
Max | dB | 4.0 | 7.0 | 9.6 | 10.4 | 12.6 | 13.5 | 16.8 | 20.5 | |
Channel Uniformity | Max | dB | 0.6 | 0.8 | 1.0 | 1.0 | 1.6 | 1.6 | 1.6 | 2.0 |
PDL | Typ. | dB | 0.1 | 0.1 | 0.1 | 0.1 | 0.2 | 0.2 | 0.2 | 0.2 |
Max | dB | 0.2 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.5 | |
Standard Grade | ||||||||||
| Insertion Loss at 23°C | Typ. | dB | 4.0 | 7.0 | 9.5 | 10.4 | 12.4 | 13.6 | 17.0 | 20.5 |
Max | dB | 4.2 | 7.3 | 10.0 | 10.6 | 12.8 | 13.8 | 17.1 | 20.8 | |
Channel Uniformity | Max | dB | 0.6 | 0.8 | 1.0 | 1.0 | 1.0 | 1.4 | 1.6 | 2.0 |
| PDL | Typ. | dB | 0.1 | 0.1 | 0.1 | 0.1 | 0.2 | 0.2 | 0.2 | 0.3 |
Max | dB | 0.2 | 0.3 | 0.3 | 0.2 | 0.3 | 0.3 | 0.3 | 0.5 | |
Return Loss | Min | dB | 55 (Premium Grade)/50 (Standard Grade) | |||||||
Directivity | Min | dB | 55 | |||||||
Operation Wavelength | nm | 1260~1650 | ||||||||
Operation Temperature | °C | -4-~+85 | ||||||||
Storage Temperature | °C | -4-~+85 | ||||||||
Fiber Type | - | G.657A or Customized | ||||||||
| Competitive Advantage |
CY strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, productsexported to Europe and the United States and Southeast Asian countri
| FAQ |
1 . When our company be established?
Answer: We started from year 2008.
2 . What's our main products?
Answer: CY dedicates to the developing, production, marketing of the Fiber Optic Cable,
Indoor/Outdoor Patch Cord, Splitter, Adapter, Attenuator, and so on.
3 . What is the area of the factory?
4 production lines for Fiber Optic Cable
2 high standard MPO/MTP Jumper assembly lines
8 production lines for standard Jumpe
4 PLC Pplitter production lines
