100M 2 Light 6 Electricity Media Converter
* Concentrated into BT-EF16-D220(16slot for media converter cards) or BT-EF14-D220(14slot for media converter standalone type) 2U rack-mount chassis.
Description
100M 2 light 6 electricity media converter
Media Converter 10/100M Fiber Optic RJ45 SC Connector
| Features |
* In conformity to IEEE802.3 10base-T, IEEE802.3u 100 base-TX/FX, IEEE802.3z, IEEE802.1a, IEEE802.1PQ0S, IEEE802.1d Spanning Tree.
* Hot Pluggable & Wall-Mountable.
* Stable performance more than 50thousand hours with fault-free.
* Unique IC solution applied.
* Supports 10/100Mbps full/half duplex, easy upgrades.
* Auto MDI/MDI-X.
* Auto Negotiation.
* Support flow control.
* Concentrated into BT-EF16-D220(16slot for media converter cards) or BT-EF14-D220(14slot for media converter standalone type) 2U rack-mount chassis.
* Stable performance more than 50 thousands hours with fault-free.
* In conformity with safety code of FCC, CE and RoHS.
| Application |
* Extend your Ethernet connection up to 0~25km away using fiber optics
* Creates an economical Ethernet-fiber/copper-fiber link for connecting remote sub-networks to larger fiber optic networks/backbones
* Converts Ethernet to fiber, fiber to copper/Ethernet, ensuring optimum network scalability for connecting two or more Ethernet network nodes (e.g. connecting two buildings on the same campus)
* Designed to provide high-speed bandwidth for demanding large scale work groups that require expansion of Gigabit Ethernet Network
| Specification |
Optical Interface | Connector | 1x9 Module SC |
Data Rate | 100Mbps | |
Duplex Mode | Full duplex | |
Fiber | SM 9/125um | |
Distance | 100Mbps:SM 25km | |
Wavelength | WDM Tx1310/Rx1550nm(A side),Tx1550/Rx1310nm(B side) | |
UTP Interface | Connector | RJ45 |
Data Rate | 10/100Mbps | |
Duplex Mode | Half/full duplex | |
Cable | Cat5,Cat6 | |
Power Input | Adapter Type | DC5V |
Power Consumption | <3W | |
Weight | Adapter Type | 0.38kg |
Dimensions | Adapter Type | 94*70*26mm |
Temperature | 0~50℃ Operating; -40~70℃ Storage | |
Humidity | 5~95%(no condensing) | |
MTBF | ≥10.0000h | |
Certification | CE,FCC,RoHS | |
| Company Profile |
Hubei Chenyu Optoelectronics Technology Co., Ltd. is a high-tech enterprise specializing in the production of optical fibers
Communication products, with nearly 10 years of industry experience. At present, the company has passed ISO9001 certification, has two production bases in Xianning and Zhongxiang, and has a large modern warehouse in Xianning. The company covers an area of 2,000 square meters and has more than 130 employees
| FAQ |
Q: What is the MOQ for this item
A: The MOQ is different for different products. We accept MOQs for most items
Q: How to order?
A: Select product → provide price list → sample/price confirmation → provide form
Invoice → deposit payment → mass production → balance payment → delivery → receipt.
Q: Do you provide samples? Is it free or extra?
A: Yes, we can provide samples for you. But it's not free. You need to pay for samples and shipping.
Hot Tags: 100m 2 light 6 electricity media converter, China, suppliers, manufacturers, factory, wholesale, cheap, low price, high quality,
