Flat 24 Core Drop Fiber Cable
4/6/8/12 enhanced low water peak single mode fibers in full compliance with ITU-T-G.652D/G.657A1
Description
| Product Description |
GYXTW 12 Core Drop Fiber Cable
Flat outdoor fiber drop cable GYFXTBY
4/6/8/12/24F (G.652D or G.657A1) suitable for aerial installation
●4/6/8/12 enhanced low water peak single mode fibers in full compliance with ITU-T-G.652D/G.657A1
●two all dielectric strength members (FRP)
●loose buffer tube fully filled and centrally placed in the cable
●UV stablized HDPE outer sheath, black
| Fiber Type |
Fibre used in the cable manufacturing fully comply to ITU-T-Rec G.652D or G.657A1
Single mode fiber | 9/125 (G.652D or G.657A1) |
Attenuation | at 1310 nm ≤0,38 dB/km |
at 1550 nm ≤0,25 dB/km |
| Waterblocking Yarn |
Type | SZS-15.0 ×4 Root |
Color | White |
| Sub Unit - Loose Tube |
Materials | PBT - polybutylene terephthalate |
Color | White |
Diameter | 2.1±0.05mm |
Number | 1 Root |
| Strength Member |
Materials | FRP - Glass fiber reinforced plastic rods |
Color | White |
Diameter | 1.5±0.05mm |
Numbe | 2 Root |
Material | PE - Polyethylene |
Color | Black |
Diameter | 3.8×7.8 ±0.2 mm |
Thickness | 0.9±0.1 mm |
| Company Profile |
Hubei Chenyu Optoelectronics Technology Co., Ltd. is one of the leading manufacturers of cables and telecommunication accessories. We have over 10 years experience in this line. Our factory has more than 20 production lines and 120 employees.
Our production complies with ISO9001. Professional team, strong factory and strict quality control give
To provide our customers with the best service and quality assurance for each order.
Our products are widely installed in telecommunications companies and many dealers around the world.
We export to more than 70 countries
We have established close relationships with many companies around the world and we sincerely look forward to working with all customers from all over the world
| FAQ |
Q1. Can I have a sample order for this product?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for sample order?
A: Low MOQ, 1pc for sample checking is available
