GYTA 24 Core Drop Fiber Cable
GYTA is an outdoor use optical fiber cable suitable for duct and aerial applications. We supply GYTA fiber optic cable from 2 fiber cores to 12 fiber cores. Both single mode type and multimode types are available.
Description
GYTA 24 Core Drop Fiber Cable
Deacription: |
GYTA is an outdoor use optical fiber cable suitable for duct and aerial applications. We supply GYTA fiber optic cable from 2 fiber cores to 12 fiber cores. Both single mode type and multimode types are available. |
The fibers, 260μm, are positioned in a loose tube made of a high modulus plastic. · The tubes are filled with a water-resistant filling compound. · The tube is wrapped with a layer of corrugated steel tape longitudinally. · Between the corrugated steel tape and the loose tube water-blocking material is applied to keep the cable compact and watertight. · Two parallel steel wires are placed at the two sides of the steel tape. · The cable is completed with PE sheath. |
Feature6 core fiber optic cable |
Low dispersion and attenuation Proper design, precise control for fiber excess length and distinct stranding process render the cable excellent mechanical and environmental properties.6 core fiber optic cable The armoring of corrugate steel tape make cable have nice properties of moisture resistance and crush resistance.6 core fiber optic cable Operating Temperature : -40~+60 ℃ |
Cable Parameters | ||
Items | Specifications | |
Fiber Count | 2~24 | |
| Colored Coating Fiber | Dimension | 260µm±15µm |
Color | Blue, Orange, Green, Brown, Gray, White | |
| Loose Tube Dimension 2.10mm±0.05mm | Dimension | 2.10mm±0.05mm |
Material | PBT | |
Color | Natural | |
| Strength Member | Diameter | 1.0mm |
Material | Steel | |
| Outer Jacket | Dimension | 8.0mm±0.1mm |
Material | PE | |
Color | Black | |
Technical Parameter | |||||
Fiber Count | Cable Diameter (mm) | Cable Weight (kg/km) | Tensile Strength Long/Short Term (N) | Crush Resistance Long/Short Term (N/100mm) | Bending Radius Static/Dynamic (mm) |
2~12 | 10.6 | 124 | 1000/3000 | 1000/3000 | 10D/20D |
14~24 | 12.0 | 147 | 1000/3000 | 1000/3000 | 10D/20D |
