1 Core Indoor Drop Fiber Cable
FTTH indoor cable is centered on the optical communication unit, with two parallel non-metallic reinforcing elements (FRP) or steel wire placed on both sides,and finally extrusion black or color poly Vinyl chloride (PVC) or LSZH (LSZH, low smoke, halogen-free, flame retardant) jacket.
Description
1 Core Indoor Drop Fiber Cable
Item | Value |
Model Number | FTTH DC-001 |
Type | Fiber Optic Cable |
Place of Origin | China |
Guangdong | |
Brand Name | Jing Tong |
Use | Indoor Ftth system |
Certification | CE/ROHS/ISO9001 |
Product name | ftth indoor/outdoor drop cable |
Model No | FTTH DC cable |
fiber quantity | 1-6 cores |
fiber color | green or blue |
fiber type | G652D /G657A/G655 |
cable color | Black or White |
Cable Structure: | Bow-type tight buffer |
Material of jacket: | UV and Flame resistant LSZH |
Strength member: | 0.5mm Steel wire or FRP |
| Pecification |
FTTH indoor cable is centered on the optical communication unit, with two parallel non-metallic reinforcing elements (FRP) or steel wire placed on both sides,and finally extrusion black or color poly Vinyl chloride (PVC) or LSZH (LSZH, low smoke, halogen-free, flame retardant) jacket.
| Features |
●Special bend-resistant fiber to provide greater bandwidth and enhance network transmission characteristics
●The cable has a simple structure, light weight and strong practicability;
●Two parallel FRPs make the cable have good compression resistance and protect the fiber;
●Unique groove design, easy to peel, easy to connect, simplify installation and maintenance;
●LSZH environmentally friendly
Fiber Type | G652D /G657A/G655 |
Fiber count | 1 |
Strength member | Steel wire/FRP/KFRP |
Supporting messenger wire | 1.0MM*x1 steel wire |
Color Of fiber | Orange, Green, Brown,Blue |
Outer sheath | LSZH |
Cable Diameter dimensions | 2.0( Height) × 5.0W ± 0.1 mm(width) |
Operation temperature range | -20 ℃ to + 70 ℃ |
Installation temperature range | -20 ℃ to + 70 ℃ |
Transport and storage temperature range | -20 ℃ to + 70 ℃ |
Tension Load (N) | Short term :600N Long term :300N |
Crush Load(N) | Long term 1000 N/100mm Short term:2200N/100mm |
Minimal installation bending radius | 30 x OD |
Minimal operation bending radius | 15 x OD |
Cable marking | The marking length 1meter apart , as required |
