Optical Splitter Box 1x32 Cassette SC/APC
Planar lightwave circuit (PLC) splitter is fabricated using silica optical waveguide technology. It features wide operating wavelength range, good channel-to-channel uniformity, high reliability and small size, and this pasiv spliter 1:32 is widely used in FTTX PON to realize optical signal power management.
Description
Product
|
Fiber optic equipment 1260 to 1650nm ftth optic fiber plc splitter 1x4 1x8 1x16 1x32 1x64
Optical Splitter Box 1x32 Cassette SC/APC
Planar lightwave circuit (PLC) splitter is fabricated using silica optical waveguide technology. It features wide operating wavelength range, good channel-to-channel uniformity, high reliability and small size, and this pasiv spliter 1:32 is widely used in FTTX PON to realize optical signal power management.
s
Feature
1) Low Insertion loss
2) Low PDL
3) Compact Design
4) Good channel-to-channel uniformity
5) Wide Operating Wavelength: 1260-1650nm
6) Wide Operating Temperature: -40°C - 85°C
7) High Reliability and Stability
Application
1) FTTX Systems
2) PON Networks
3) CATV Links
4) Optical Signal Distribution
5) Local Areal Networks (LAN)
6) Fiber Communication Systems
Specification
Parameters | 1×2 | 1×4 | 1×8 | 1×16 | 1×32 | 1×64 |
Operating Wavelength (nm) | 1260~1650 | |||||
Fiber Type | SMF-28e or customer specified | |||||
Insertion Loss (dB)(S/P Grade) | 4.0/3.8 | 7.3/7.0 | 10.5/10.2 | 13.7/13.5 | 16.9/16.5 | 21.0/20.5 |
Loss Uniformity (dB) | 0.4 | 0.6 | 0.8 | 1.2 | 1.5 | 2.5 |
Return Loss (dB) (S/P Grade) | 50/55 | 50/55 | 50/55 | 50/55 | 50/55 | 50/55 |
Polarization Dependent Loss(dB) | 0.2 | 0.2 | 0.3 | 0.3 | 0.3 | 0.4 |
Directivity (dB) | 55 | 55 | 55 | 55 | 55 | 55 |
Wavelength Dependent Loss(dB) | 0.3 | 0.3 | 0.3 | 0.5 | 0.5 | 0.5 |
Temperature Stability(-40~85 °C)(dB) | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
Operating Temperature (°C) | -40~85 | |||||
Storage Temperature (°C) | -40~85 | |||||
Packaging Dimension (mm) (L×W×H) | 40×4×4 | 40×4×4 | 40×4×4 | 40×4×4 | 50×7×4 | 60×12×4 |
Notes
1.Specified without connectors.
2.Add an additional 0.2dB loss per connector
Product Type | PLC Splitter-1 |
Channel number | 1x32 /1xN/2xN Custom |
Wavelength Range （nm） | 1260~1650nm |
Package dimension(mm) | 60x7x4mm /60x12x4mm/ 70x12x4mm/80x12x6mm/100x40x6mm |
Fiber Type | Corning SMF-28e G652D Corning SMF-28e G657A1 Corning SMF-28e G657A2 |
Fiber length | 0.5/1M/Custom |
In/Out Connector | SC/FC/LC UPC/APC |
HS Code |
| FAQ |
1. What is your order quantity?
CY: usually 1 piece/piece, if you have detailed requirements, you can coordinate.
2. What is your delivery date?
CY: The delivery date is approximately 7-9days, depending on the order quantity.
3. Can you provide samples for customers?
CY: Of course, but the shipping charges will be charged in the customer's account.
