8 Core MPO Patchcord
MPO/MTP trunk multicore cable assemblies facilitate rapid deployment of high density backbone cabling in data centers and other high fiber environment, reducing network installation or reconfiguration time and cost, they are used to interconnect cassettes, plane or fan outs.
Description
| Product Description |
MPO/MTP trunk multicore cable assemblies facilitate rapid deployment of high density backbone cabling in data centers and other high fiber environment, reducing network installation or reconfiguration time and cost, they are used to interconnect cassettes, plane or fan outs. It offered in fiber types in standard 8, 12, 24 or 48 cores versions using a compact and rugged microcables structure.The compact cable optimize cableway use and improve airflow.These MPO/MTP cable are built with highest quality components.Low loss elite versions are offered, featuring low insertion loss for demanding high speed networks where power budgets are critical.
| Features |
* US Conec MTP® connector, Senko MPO Plus premium connector
* Corning® Clearcurve® multimode fiber, SMF-28® Ultra Optical Fiber
* OS2, OM3, OM4 fiber grades (OM1 and OM2 available)
* 35dB Elite low loss MTP/MPO connector as well standard versions of 0.6/0.75dB
* Factory terminated and tested
* Allow easy migration from 10GbE to 40GbE or 100GbE
* Pulling eyes are provided as an option to protect the fiber ends during installationSemi-Automatic PET Bottle Blowing Machin
| Specification |
Model | SM | MM | |
Connector A:MPO/MTP | |||
Connector Fiber Count | 8,12,24,48 Core | ||
Polish | PC,APC | PC | |
Insertion Loss | Standard | ≤0.70dB | ≤0.50dB |
Elite Low Loss | ≤0.35dB | ≤0.30dB | |
Return Loss | PC≥50dB,APC≥60dB | ≥30dB | |
Durability(500 Matings) | ≤0.2dB | ||
Test Wavelength | 1310/1550nm | 850/1300nm | |
Connector B:LC,LC Uniboot,SC,FC,ST | |||
Polish | PC,APC | PC | |
Insertion Loss | ≤0.2dB | ≤0.2dB | |
Return Loss | PC≥50dB,APC≥60dB | ≥35dB | |
Durability(500 Matings) | ≤0.2dB | ||
Test Wavelength | 1310/1550nm | 850/1300nm | |
| Company Profile |
Founded in 2012, Hubei Chenyu Optoelectronics Technology Co., Ltd. is a high-tech enterprise and the world's leading supplier of optical fiber components.
Now we are the largest supplier of optical fiber components in South China. Our main products are various fiber optic and FTTH products, such as fiber optic Pathcords, fiber pigtails, fiber optic adapters, fiber optic and FTTH couplers, PLC splitters, WDM/CWDM/DWDM, full range of distribution boxes and FTTH products.
All our products meet international quality standards and are well received in a variety of different markets around the world!
| FAQ |
Q1. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q2. How to proceed an order for the product?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q3: Do you offer guarantee for the products?
A: 30 Years' Guarantee
