Description
10G 1310nm LC Tosa Rosa
| Features |
High Responsivity
Small dark current
High reliability
FTTH,SDH,SONET
| Optical&Electrical Characteristics |
Parameters | Symbol | Min | Typ | Max | Unit | Test conditions |
Power Supply | Vcc | 3.0 | 3.3 | 3.6 | V | |
Supply Current | Icc | 44 | 60 | mA | no loads | |
Differential Responsivity | Rd | 1.4 | 3.0 | mW/uW | Rload=100ohm P=-18dBm,λ=1310nm | |
Single Ended Responsivity | Rs | 0.7 | 1.5 | mV/uW | Rload=50ohm P=-18dBm,λ1310nm | |
Small-Signal Bnadwidth | BW | 1.65 | GHz | |||
Low-Frequency Cut off | LF | 5 | kHz | |||
Rise/Fall Time(20%~80%) | tr/tf | 150 | 200 | ps | P=-18dBm,λ1310nm | |
Saturation Power | Psat | -3 | dBm | λ=1310nm | ||
Single Ended Output Impedance | Ro | 40 | 50 | 60 | ohm | |
Wavelength | λ | 1270 | 1620 | nm | ||
Sensitivity | -22 | dBm | λ=1310nm,@2.5Gbps, PRVS7,ER=10dB,BER=1E-10 |
